TPI-4000-VFG-C
- Ask your local dealer for pricing and availability.
- Most products have a minimum 2-year manufacturers warranty.
- Direct shipments available, ask your dealer.
This air inlet is suitable for almost all applications. With a center-hinged inner flap, the air is distributed and also flows under the flap when opened more than 25%. The inlet is operated with a central plastic control arm. This inlet is equipped with a curved inner flap, when opened for maximum ventilation, the air is also directed down towards the animals. The square shape and the slightly curved inner flap of this inlet make it particularly suitable for wider stables where a larger throw is desirable.
Capacity in m3 / hour at a static pressure of:
Product information:
| Run | 63 cm / 24.6 Inch |
| Force | 2 kg / 19.6 Newton |
| Number / pallet | 18 (1.20 x 0.80 x 2.40 m) |
| Weight / per inlet | 4 kg / 8.8 Lbs |
| Volume / per box | 9 |
